AITR Medical Insulation Transformer
● Insulation Transformer for Hospital IT Power System
● Double Insulation Treatment
● Electrostatic Shielding Layer
● PT100 Temperature Sensor Embedded in the Winding
● CE; IEC 61558-1:2009; IEC 61558-2-15:2011; IEC60364-7-710:2016

PRODUCTS

  • Features

    Insulation Transformer for Hospital IT Power System


    ● Inrush Current(IE): <12Ln


    ● Short-circuits Voltage: <3% Un


    ● Noise Level: <40dB (A)


    ● Efficiency: >96%



    Multiple Insulation Treatment


    ● Leakage Current:  <200μA


    ● Insulation Class: H



    PT100 Temperature Sensor Embedded in the Winding


    ● Thermistor: PT100


    ● Temperature Measuring Range: -50℃~+200℃



    Wiring Instruction




    Typical Application


  • Rated Capacity
    		3.15kVA/5kVA/6.3kVA/8kVA/10kVA
    Frequency50/60Hz
    Rated input voltage230V
    The output voltage230V/115V
    Inrush current<12In
    Leakage Current<200uA
    No-load output voltage<235V
    No-load output current<3% In
    Short-circuit voltage<3% Un
    Efficiency>96%
    Maximum ambient temperature<40℃
    No-load temperature rise<33℃
    Full load temperature rise<76℃
    Withstand voltage4200V/Min
    Insulation ClassH
    Noise Level <40dB (A)


  • External dimensions of AITR series medical isolation transformer (unit: mm)

    20200708164557994.png@!w1600

    External dimensions of AITR series medical isolation transformer



    Table 9 External Dimensions of AITR Series Medical Isolation Transformer

    TypeCapacity (VA)A(mm)B(mm)C(mm)D(mm)E(mm)F(mm)Total weight (kg) (mm) (mm) (kg)
    AITR1000010000280275427240190φ1192
    AITR80008000280265427240190φ1190
    AITR63006300280255427240175φ1175
    AITR50005000280255427240175φ1173
    AITR31503150280225427240175φ1153
